GOM New software for high-performance CT data analysis in 3D

| Editor: Steffen Donath

GOM announces the new software solution GOM Volume Inspect offering volume visualisation and inspection features for analysing volume data collected from any available computed tomography system.

Related Companies

Visual GOM volume inspect: Complete CT data analysis in 3D.
Visual GOM volume inspect: Complete CT data analysis in 3D.
(Source: GOM)

GOM Volume Inspect comes with a full 3D data analysis to evaluate a part’s quality and to optimise the manufacturing process. As the software features a clever on-demand data management concept, it delivers high performance at any time — even in case of huge volume data packages — and speeds up analysis processes.

Volume renderer and intuitive generation of sectional views GOM Volume Inspect includes a powerful volume rendering function which visualises the whole part including the internal structures, the company states. Furthermore, the user can cut the object at any point and view it layer by layer in order to see smallest details and gain in-depth information about the quality of the part.

Wide range of analysis criteria and result presentation

The software also automatically detects any volume defect in a part, such as shrinkage cavities, and accurately evaluates the quality by checking defect dimensions including volume, diameter and distance from outer casing.

Moreover, it is possible to evaluate the dimensions of CT volume data — be it full-field evaluations, GD&T or inspections of geometric dimensions on the outside of the part as well as on internal structures. GOM Volume Inspect walks the user through the complete analysis process and delivers the measured results in a transparent report with a single mouse click. The report may include snapshots, images, tables, charts, text and graphics.

Screenshot shrinkage cavities: The results can be shown in a clear color representation giving a good overview of the part.
Screenshot shrinkage cavities: The results can be shown in a clear color representation giving a good overview of the part.
(Source: GOM)

Many volume inspection features for free

GOM Volume Inspect comes with a broad range of volume inspection functionalities for free, including 3D volume rendering, display of 2D volume slices as well as defect detection and visualisation. The free software can be downloaded here: link
