Components Meusburger puts the right spring in your projects

Editor: Alexander Stark

Germany — The extensive range of springs offered by Meusburger covers demands ranging from very low to extremely high loads. The company makes ordering easy with their new compression spring wizard.

Related Companies

The system compression spring wizard from Meusburger simplifies the design process.
The system compression spring wizard from Meusburger simplifies the design process.
(Source: Meusburger)

To make the design process for customers as simple as possible, Meusburger created a wizard for selecting the right system compression spring. Intuitively designed and easy to use, the wizard helps customers select the right spring with just a few clicks. The configurable data is then available for download.

First the following parameters can be entered:

  • Service life
  • Number of springs (if the number is increased, the result is calculated on the complete spring set)
  • Installation length preloaded
  • Initial force at preload
  • Stroke
  • Spring force in end position
  • Outside diameter

Then a list of matching system compression springs is displayed, sorted by outer diameter and starting with the smallest possible diameter. Finally, it is possible to generate the CAD data — in both installed and uninstalled condition. With the help of the system compression spring wizard, the right spring can be found quickly for every application.
