Husky Award-winning Ultra Helix 250 T2 nozzle for small parts

| Editor: Steffen Donath

Husky Injection Molding Systems is proud to announce the release of the newest addition to the Ultra Helix™ Valve Gate nozzle lineup, the Ultra Helix 250 T2.

Related Companies

Husky releases a new award-winning nozzle.
Husky releases a new award-winning nozzle.
(Source: Giorgio Trovato)

The advanced design of Ultra Helix nozzles minimises wear, providing industry leading gate quality and longevity. The award-winning Ultra Helix 250 T2 was specifically developed to extend the benefits of the Ultra Helix technology for small part weights with difficult to access gate locations.

Direct gating for small parts

With a 12 mm nozzle bore, the Ultra Helix 250 T2 allows for direct gating in locations not achievable with larger nozzles. The pitch spacing down to 15 mm enables the highest cavitation density and smallest mould footprint.

Reduced maintenance

The Ultra Helix 250 T2’s extended maintenance interval PX actuation is designed for applications with leakage prone resins like TPE and PE. The addition of a stem seal paired with enhanced thermal management heater technology improves performance and significantly optimizes maintenance requirements. This results in lower risk and cost of ownership.

Three actuation options available

The Individual Pneumatic option offers pitch spacing down to 25.4 mm, providing ease of access for maintenance with the ability to individually access valve stems without removing the backing plate. Both the plate actuated Ultrasync-P or servo driven Ultrasync-E options can achieve 15 mm pitch spacing.

Producing part weights of less than 0.1g

Husky’s global customers are already taking advantage of the Ultra Helix 250 T2’s performance to make high quality precision parts from medical barrier closures and flow regulation valves to personal care products, food and beverage packaging and flip top closures, according to the company. The part weights being produced range from less than 0.1 g to over 4 g and are being made from resins that are prone to leakage like PP, HDPE, LDPE, TPE and TPV, in both single injection and multi-material applications. The Ultra Helix 250 T2 is already demonstrating its superior performance for small part weight with difficult to access gate location applications in both Individual Pneumatic and Ultrasync actuations. The extended maintenance interval for leakage prone resins is providing additional value for the customer.

Award winning technology

The Ultra Helix 250 T2 received an award at the 2020 Plastics Industry — Ringier Technology Innovation Awards in the Mold and Component category. Contending products were evaluated based on their ability to improve product efficacy through technological innovation or provide new business opportunities for the market. Winners were selected by professionals from industry associations and scientific research institutions.

The features and benefits of the Ultra Helix 250 T2 make it the ideal solution for specialty and flip-top closures, small medical parts and multi-material parts with limited gate access.
