EDM

The Intelligent Spark Protection System (ISPS) can automatically control and adapt the cutting parameters of a wire-cutting EDM machine, ensuring an improved, safe cutting process without wire breakage.

Contaminated or dirty dielectric fluid can negatively affect the Electrical Discharge Machining process causing problems such as slower cutting speeds, metal removal rate and lower quality and rejected parts that fail quality control.

One of the Mitsubishi machines in action at N&E Precision.

Makino’s EDAC1 is capable of producing corner radii of 0.00019 inches (0.005mm) and surface-finish quality of 0.000024 inches (0.6 micron) Ry, while providing repeatability in the submicron range.

Sodick technology installed at Styles Precision with Jim Seccombe, Styles Precision Technical Manager

Electric discharge machining does not use any force to remove material. Instead, an electric discharge occurs between workpiece and tool. In this case, a wire is used to “cut” the material.

A cable tie plastic injection mould being sparked on the EDNC6.

The special feature of the innovative EDG technology is the combination of electrical discharge machining and mechanical grinding.
