Laser scanning systems New laser scan systems for micromachining and a multi-head setup

Related Vendors

SCANLAB GmbH

AMETEK GmbH Division Creaform Deutschland

Meusburger Georg GmbH & Co. KG

Renishaw plc

At Laser World of Photonics, Scanlab showcases its latest high-speed scan systems and innovations for industrial laser applications. Highlights include live demos of the Scancube IV 7 in a synchronized multi-head setup, new models in the Intelliscan IV series, and an interactive Innovations Board offering insights into cutting-edge development projects.

The OEM manufacturer of laser scanning systems, Scanlab, is using the Laser World of Photonics trade fair in Munich to present numerous new products. From June 24, visitors can witness the Scancube IV 7 in action at the Munich exhibition center: In a multi-head setup, six synchronized scan heads impressively demonstrate the speed that the new system offers. They can also discover the completed, particularly productive Intelliscan IV product family and take an interactive look behind various development projects and discuss them with product experts.

The compact high-performance scan heads of the Intelliscan IV product family have been further extended. The new Intelliscan IV 10 scanner with 10-millimeter aperture is ideal for use in micro material processing and structuring. With the innovative Scanahead control, it achieves write speeds of around 1,310 cps in good quality. The achievable maximum speed corresponds to 360 rad/s or a remarkable 57.6 meters per second when using a lens with a focal length of f = 160 mm.

The second new addition is the Intelliscan-se IV 30 with digital encoders. The latter provide it with a significant increase in long-term stability combined with maximum precision, which makes it ideal for additive manufacturing. All laser scan heads in this series set standards in terms of compactness, performance and integration capability. Thanks to the reduced dimensions, integrated water cooling and a dust and water-protected housing with IP66 protection class, they are ideally equipped for demanding industrial use. Users can choose between classic scanner control with tracking delay and the particularly dynamic Scanahead control. Further apertures with digital encoders will follow in the next 12 months. In addition, all these scan systems are “ready for Scanmotion Control”.

Synchronous scanning and a look behind the scenes

Another show highlight is the multi-head setup with the Scancube IV 7, which was only presented at the beginning of the year. Six scanners arranged in a row demonstrate their joint dynamic peak performance live. Reliable synchronization is achieved with RTC6 control boards. The particularly compact scan heads are especially suitable for laser marking and coding thanks to their high writing speeds of up to 1,840 cps.

For the first time, Scanlab will be presenting its various development projects with an interactive “Innovations Board” at the trade fair. The innovations include a new solution approach for beam shaping, a concept idea for a modular welding scanner, a self-tuning approach for individual on-site adjustments as well as the new software framework for additive manufacturing. Visitors can talk to the respective product managers in person and discuss their own requirements.

(ID:50457929)
